Hikvision 2mp Camera 1080p

Product Description


  • Adopt latest 1/3″ SONY 1080p DWDR CCD
  • Ultra high resolution 1080p
  • Hi-efficiency IR
  • Aspherical 3.6/2.8/12mm lens with Auto Iris & IR-CUT Module
  • Most cutting edge 2D + 3D-DNR(Digital Noise Reduction) with Anti-blur technology extremely improve the low-light environment with superior image quality
  • Motion detection (Frame rate link)
  • HLC (High Light Compensation)
  • E-zoom
  • Preset OSD menu for more intuitive operation
  • The day and night real conversion function, you can directly drive filter ICR double switch
  • New wide dynamic (DWDR) function, in contrast, relatively strong light can get a good case of the dynamic image effect
  • Superior color resolution


  • To prevent shock or damage to the waterproof body, tighten all the screws and cover
  • Adjust the visor to prevent the lens from direct sunlight
  • Do not directly touch the front glass. To clean the dust, wipe with soft cloth with alcohol.
  • Do not install camera where vibration is present.
  • Do not install camera where temperature is above 50°C or below –20°C
  • Do not expose power or video connection to moisture or water.
  • If camera is not functioning properly, please power off and contact the manufacturer.

Note: Non-regulated power supply may cause damage to camera.

Technical Specifications

Product Name Professional DWDR IR Camera
Video System NTSC/ PAL System
Sensor 1/3″ SONY DWDR CCD
Resolution 1080p
Day & Night CDS Control
Burst ON/ OFF
Signal Noise Ratio ≥56Db (AGC OFF)
ESC Auto Shutter PAL: 1/50(Sec.)~1/100,000(Sec.); NTSC: 1/60(Sec.)~1/100,000(Sec.)
Slow Shutter Yes
Sensitivity Can be adjusted
Lens Type Auto/Manual
Syn-system Inter-sync & Line Lock Mode
Motion Detection On/Off
Privacy 15 Areas Selectable, Area selection/Display/position/color/Transparency/Mosaic
Mirror Off, V-Flip, H-Flip, HV-Flip
Sharpness 0~15
White Balance ATW/Push/User1/User2/Manual/Push Lock
Auto Gain Control 6,12, 18, 24, 30, 36, 42, 44.8 DB optional
Picture Adjust Brightness/Contrast/Sharpness/Hue/Color Gain
Digital Image Stabilizer Yes
Lens Shading Compensation Yes
Coaxial Communication Yes through UTC
OSD Language
E-zoom On/Off
DIS On/Off
Scene Select Custom/Full Auto/Indoor/Outdoor/Backlight/ITS
Exposure Mode Electronic Exposure
Shutter/AGC Auto/Manual/Fix
Min. Illumination 0LUX (IR LEDs ON)
IR LEDS Hi-efficiency IR LEDs
IR Distance 20M
Voltage Input DC12V±10%
Power Current 120mA (LEDs off), 330mA (LEDs On)
Operation Temp. -10°C~50°C
Storage Temp. -20°C~60°C
Humidity Range 20%~90% RH
