Feature:
- High-Speed Progressive CMOS sensor,
- Full HD Resolution: 1920* 1080P / 30fps; 1280*720P/60fps
- WDR (Wide Dynamic Range) Newest WDR technology. Each pixel processed independently for improved picture
quality in scenes consisting of both bright and dark areas - DNR (Digital Noise Reduction, 2D+3D ): The DNR technology eliminates noise thus generating a distinct and clear
image. This camera DNR function utilizes both an adaptive 2D filter reducing noise in the brightness of the image and
an adaptive 3D filter reducing noise caused by movement. - Privacy mask Function : The privacy zone function makes it possible to make specific areas of the scene from
view. - Intelligent motion detection : You can transmits an alert signal when it detects motion of an object on the
screen. This feature is useful when you have to monitor several screens simultaneously. - Defog : Defogging foggy video image.
- Simple and easy installation with new or existing coaxial infrastructures
Installation:
- To prevent shock or damage to the waterproof body, tighten all the screws and cover
- Adjust the sunshield to prevent the lens from direct sunlight.
- Do not directly touch the front glass. To clean the dust, wipe with soft cloth with alcohol.
- Do not install camera where vibration is present.
- Do not install camera where temperature is above 50°C or below -20°C.
- Do not expose power or video connection to moisture or water
- If camera is not functioning properly, please power off and contact the manufacturer.
Note: Non – regulated power supply may cause damage to camera.
Technical Specifications:
| Product Name | Full HD-SDI IR Eyeball Dome Camera |
| Image Sensor | 1/2.8″ Sony Exmor High Sensitivity Sensor |
| Total Pixels | 2000H*1121V (2.0M Pixel) |
| Active Pixel | 1936H*1105V (2.12M Pixel) |
| System | NTSC /PAL |
| Resolution | Digital: 1920*1080P; 1280*720P / Analog: 700TVL |
| Lens | 3.6/6/8/12/4-9/2.8-12mm Megapixel Lens With Auto Iris and IR-CUT Module |
| Min. Illumination | Color: 1.0Lux, BW: 0.5Lux / Color DSS: 0.002Lux; BWDSS: 0.001Lux |
| Video Output | HD: HD-SDI / Analog: NTSC/ PAL (without WDR) |
| S/N Ratio | More than 50dB (AGC off) |
| Mode | D&N/ COLOR/ IR CDS |
| Brightness | 0~20 Steps |
| Shutter Speed | Auto/ Manual (1/30(1/25)~1/60000) |
| DSS | OFF/x2 /x3 /x4 |
| AGC | 0~20 |
| Flickerless | OFF/ON |
| WDR/BLC | OFF/WDR/BLC |
| Day & Night | Auto /Day /Night /Ext |
| White Balance | Auto /One Push /Manual /Indoor /Outdoor |
| HLC | OFF /ON /Night |
| DNR | OFF /Low /Middle /High /Auto |
| Mirror | OFF /H /V /H&V |
| Sharpness | 0~10 Steps |
| ACE | OFF /ON |
| Defog | OFF /ON |
| Freeze | OFF /ON |
| Gamma | 0.45 /0.50 /0.55 /0.60 /0.65 |
| E.Zoom | x1~x7 |
| Privacy | OFF /ON (32 points) |
| Motion | OFF /ON (4 points) |
| Language | English/ Chinese |
| LEDs | 30LEDs IR 30m distance |
| Power Input | DC12V ± 10% |
| Power Consumption | 70mA |
| 305 mA | |
| Operation Temp. | -10°C~50°C (Humidity: 0%RH~80%RH) |
| Storage Temp. | 20°C~60°C (Humidity: 0%RH~80%RH) |
| Dimension | Φ140*89 mm |
| Weight | 750g |
